Product Name:Cutting Plotter Vinyl-PC0812

Product Details:
Model:
PC0812
Select Payment and Shipping Terms:
Min. Order Quantity:
1 Roll/Rolls
Place of Origin:
Min. Order:
FOB Price:
0.00-0.00 /
Shipping Terms:
Shippment Port:
Shanghai
Payment Terms:
L/C ,T/T
Show Buyers your Ability to Supply:
Production Capacity:
0 per 15 Days
Delivery Time:
Packaging:
Hard Carton (all packing are neutral packing)

Detailed Product Description:

Specification of Cutting Plotter Vinyl PC0812
Items  Description
Surface Material
 Type Glossy,Colourful,Calendered polymeric PVC Film
Thickness of film 80 micron
Tensile Strength ≥16N/mm2
Elongation ≥80 MD/CD
Surface tension ≥30DN/CM
Shrinkage ≤1.0%
Adhesive
 Type Solvent based clear adhesive
Dried coated weight 20 ±2 gsm
DT20min peel >600g/25mm
DT24hrs peel >800g/25mm
Shearing force >1000min
Release force 50-150 g/50mm
Liner
 Type One-side silicone paper

Weight 120 gsm
Size Width 1.06/1.23m
Length 50m
Durability 1 year（Proper application & normal condition）
Remarks: The above mentioned content are the average data summarized by Precede under the latest test result. The tolerance should be ±5％.
